USB Programmer CH341A Series Burner Chip 24 EEPROM BIOS Writer 25 SPI Flash + CD

Description:
100% brand new and high quality
Support 24EEROM
Support 25 SPI Flash
Automatic identification chip model 25 series
Support USB to TTL
A multi-purpose machine, online Brush
STC microcontroller supports a full range of program download
For a variety of software for backup, erase, programming, calibration and other movements
Provide 5V-3.3V power supply output
Dimension: 70mm x 27mm

Features:

USB 2.0 interface,

The speed of reading and writing is very fast.

support Win 98 ，Win ME ，Win 2K ，WinXP ， Win VISTA ，Win 7 - 32bit/64bit , Win 8 - 32bit/64bit , Win 10 - 32bit/64bit

Speed: 2-3M/min
Using recoverable automatically fuse the event of the the chips short-circuit or chip installed anti will automatically power off ( indicator turns off ) to avoid motherboard , programmer and chip burn out , short circuit exclude automatic recovery

Support chips list:

AMIC：
·A25L05P，A25L10P，A25L20P，A25L40P，A25L80P，A25L16P

ATMEL：
·AT25DF041A，AT25DF321，AT25F004，AT25F512A，AT25F2048，AT25F4096，AT25F1024A，AT25FS010，AT25FS040，AT26DF081A，
·AT26DF161A，AT26DF321，AT26F004

EON：
·EN25B05，EN25P05，EN25B10，EN25P10，EN25BF20，EN25P20，EN25F20，EN25B40，EN25P40，EN25F40，EN25B80，·EN25P80，EN25F80，EN25T80，EN25B16，EN25P16，EN25B32，EN25P32，EN25B64，EN25P64

Excel Semiconductor Inc.
·ES25P10，ES25P20，ES25P40??ES25P80，ES25P16，ES25P32

ST：
·M25P05A，M25P10A，M25P20，M25P40，M25P80，M25P16，M25P32，M25P64，M25PE10，M25PE20，M25PE40， M25PE80，M25PE16，M25PE32，M45PE10，M45PE20，M45PE40，M45PE80，M45PE16，M45PE32

MXIC：
·MX25L512，MX25L1005，MX25L2005，MX25L4005，MX25L8005，MX25L1605，MX25L3205，MX25L6405

MX25L6445,MX25L6405(SOP16)

NexFlash：
·NX25P80，NX25P16，NX25P32

Chingis Technology Corporation
·Pm25LV512，Pm25LV010，Pm25LV020，Pm25LV040，Pm25LV080，Pm25LV016，Pm25LV032，Pm25LV064

Saifun Semiconductors
·SA25F005，SA25F010，SA25F020，SA25F040，SA25F080，SA25F160，SA25F320，

WINBOND
·W25P10，W25X10，W25Q10，W25P20，W25X20，W25Q20，W25P40，W25X40，W25Q40，W25P80，W25X80，W25Q80， W25P16??W25X16，W25Q16，W25P32，W25X32，W25Q32，W25P64，W25X64，W25Q64
